FLEX CS 45 18.0-EC C Circular Saw

• The saw's design ensures perfect balance for freehand use. The handle is positioned in a
• Line with the saw blade, which facilitates precise guidance of the saw along the scribed line and without
• Rail system supports straight cutting results
• Ideal for classic applications in drywall construction and renovation. For example, for saw cuts through gypsum plasterboard, concrete fiberboard, wood-based materials such as formwork panels, and chipboard or OSB panels.
• Brushless motor with higher efficiency and longer lifespan
• 18.0 V EC motor with overload protection and temperature monitoring
• The motor brake stops the saw blade in 2 seconds.
• Electronic Management System (EMS) protects the machine, extends its service life and increases efficiency
• Compact and ergonomic design
• According to the latest regulations, without a riving knife for plunge cuts and without the need for complex removal of the riving knife.
• Cutting depth adjustment via self-explanatory clamping lever
• Spindle lock: for quick saw blade changes
• Connection option for external dust extraction with Ø 27 mm or step adapter
• LED battery capacity indicator
• FLEX battery system: Compatible with all FLEX 18.0 V battery packs. Supplied without battery or charger.

Basic equipment:

• 1 dust bag, 1 piece
• 1 suction adapter (1 piece)
• 1 parallel fence (1 piece)
• 1 saw blade 517.682

Technical data:

• Battery voltage: 18.0 V
• Battery capacity: 2.5 / 5.0 Ah No-load speed: 5400 rpm
• Saw blade holder: 20 mm
• Cutting depth: 0-46.5 mm
• Saw blade diameter: 128 mm
• Dimensions (L x W x H): 315 x 120 x 262 mm
• Weight without battery: 2.4 kg
