GEDORE Universal Puller 2-arm 130x100 mm

For safe and quick removal of discs, wheels, ball bearings, etc.
Sturdy, ergonomically shaped crossbeam with bending moment reinforcement
The ergonomically designed traverse features even stronger and safer pull-off torques thanks to the bending moment reinforcement at the back.
Adjustment scale for even adjustment of the trigger hooks. Allows for a centered and force-optimized trigger pull even at the highest trigger forces.
The quick adjustment supports ergonomic and fast working methods.
Interchangeable spindle tip (ball or point)

• 3D data available: No
• Anti-slip protection on the spindle: No
• Number of arms: 2
• Number of hooks: 2
• Design: 2-arm
• Maximum load on the entire puller [t]: 3 t
• Hooks can be moved parallel to each other: Yes
• Hook brake present: No
• Hook foot width at the usable surface c1 [mm]: 22 mm
• Hook foot diameter at the tip e1 [mm]: 3 mm
• Hook foot depth usable d2 [mm]: 12 mm
• Hydraulic spindle optional: -
• Hydraulic spindle present: No
• Contents (number of pieces): 1 pc.
• Retrofittable with hydraulic spindle: No
• Net weight [g]: 1200 g
• Net weight [kg]: 1.2 kg
• REACH registration: No
• Wrench size of operating hexagon: 17 mm
• Quick-release levers available: Yes
• Screws included: No
• Scale divisions available: Yes
• Tensioning brackets available: No
• Usable clamping depth b [mm]: 100 mm
• Span for external skiving (max.) [mm]: 130 mm
• Span of internal skiving a2 (max.) [mm]: 170 mm
• Span for internal skiving a2 (min.) [mm]: 70 mm
• Spindle slip protection: No
• Spindle pressure piece type: Ball & Point
• Spindle thread size: M14x1.5x140mm
• Spindle thread length (usable) [mm]: 140 mm
• Spindle surface coating: Nitrocarburized
• Spindle wrench size: 17 mm
• Spindle tip replaceable: Yes
• Reversible arms available: Yes
• Country of origin: Germany
• Use/Application: For removing drive pulleys, wheels, ball bearings, etc.
• Customs tariff number: 82055980
• Maximum tractive force [t]: 3 t
